제품 상세 정보:
결제 및 배송 조건:
|
| 표준: | EMV, PBOC, PCI | 디스플레이: | 19 인치 TFT LED 터치 스크린 |
|---|---|---|---|
| EPP: | PCI 4.0은 16개 버튼을 증명했습니다 | 카드프린터: | 카드 판독기와 침판 빗질기 프린터 |
| 돋을새김: | 지원 압인과 후방 상품 주문, 팁핑 | 카메라: | 720P |
| 카드리더: | 비접촉식, 접촉, 자기 띠 | 지문: | 전기 용량 지문 스캐너 |
| 강조하다: | 19in Touch Screen ATM Machine,LED Touch Screen ATM Machine,EMV ATM payment machine |
||
Smart Teller Machine STM Bank bank lobby Kiosk for card issuing
PRODUCT DESCRICPTION
WCT-260T is the newest smart self service bank kiosk designed to improve branch efficiency and enhance user experience. Combined with Wisecard smart banking system and machine control platform it builds up a turn-key smart branch solution for commercial banks.
1, Self service apply for a bank card.
2, Self service to check your account amount.
3, Self service to transfer money to other account.
4, With easy to operate smart touch screen and thermal receipte printer.
5, Easy for installation and maintenance.
6, With UPS power inside to avoid power faliure suddenly.
7, Floor standing can be put at any place.
Wisecard Smart Banking Solution
The Wisecard Smart Banking solution is highly compatible with numerous of CMS packages and Third Party systems.
Additionally we offer a Software Development Kit(SDK)to implement customizations inhouse,or customization service to meet a bank' s specific requirements.
Instant Card Printer & Embosser
Compatible with all the features of unselectable card dispenser
Instant changing card with same card number
Instant personalized DIY card printing
(make new card with personalized picture/card number on spot)
Print and dispenser card according to spot customer' s needs(reduce sleep / inactive card)
| ModuleTechnical Specifications | |
| Cabinet & Accessories | Hard, thick and non-deforming materials； |
| Surface treatment process:rust-proof, antiseptic, anti-friction； | |
| Neat internal wiring, using drag track and frontdoor for easy maintenance；Independent ventilation system in line with bank requirements | |
| SIU | Sensors and Indicators Unit |
| Industrial PC | CPU:Core I series or equivalent technical indicators |
| Harddrive:500G | |
| Memory:4G | |
| Display | Display:19"4:3 TFT LED； |
| Resolution:1024*768(inclusive)ormore； | |
| Anti-glare(flim) :left and right viewing angle<=30°； | |
| TouchScreen | Touchscreen:19*4:3； |
| Resolution:4096*4096； | |
| Special requirements:anti-dust/riot/scratch； | |
| Receipt Printer | Support full graphic printing； |
| Width:80mm； | |
| Chinese font:Arial or traditional； English Font； | |
| Support GB 18030 character set and GBK character set； | |
| Blackspot recognition； | |
| Continuous paper printing, automatic cutting.to provide semi-cut/full cut function； | |
| EPP | PCI 4.0 certifed, |
| 16 buttons | |
| Support duplex printing； | |
| PASS BCTC test and certification: | |
| Flat Card printer(with cardreader) | Support PBOC, EMV standards； |
| Six card hoppers with independent lock； | |
| print:picture,photo,name,validity,CVV,and etc； | |
| Six card-dispensing box, bot al capacity are:600 pcs flat card； | |
| Double card-collecting box:total capacity:150 pes flat card. | |
| Embosser | Support Embossing and rear indent, Tipping |
| Pass BCTC test and certification； | |
| Support PBOC, EMV standards； | |
| Camera | Support concealment； |
| Support 720p. | |
| ID CardReader* | Electrically load in card |
| Meet the requirements of the Ministry of Public Security； | |
| Compulsory return ID card. | |
| Fingerprint Scanner | Capacitive； |
| Detection of dermis. | |
| Contactless CardReader | Secure module available； |
| Follow ISO/IEC 14443 standard； | |
| Support EMV standard requirements； | |
| Power Fi Safeguard function for the data stored in the card reader | |
| Human Sensor | Can sense that customer is standing in front. |
| OS | WIN 7, WIN10 or other OS |
| Digital Pen | Handwriting fidelity；Integrated handwritten signature board + electromagnetic induction pen； |
| BarCode Scanner" | Support both one dimension and two-dimensional code(QR code) |
Company Information:
Wisecard (a WiseGroup company) is a global solution provider that has been providing innovative payment and secure solutions to financial institutions, government entities and telco operators worldwide.
Wisecard have been providing EMV smart card, EMV biometric card, EMV perso software, card issuance, EMV embossers, Smart POS machine, Android POS, POS terminals, smart banking, smart teller machine, kiosk, vending machine, biometric POS, Hardware Secure Module, mobile payment platform, private label card solution, prepaid card solution, card management system to partners in more than 60 countries worldwide. Wisecard’s product suite empower large global financial institutions and government sectors as well as small to medium sized retail banks.
Wisecard solutions are adapting to the highest and latest secure standard, and the solutions have been fully tested and certified by international test labs, like FBI, STQC, EMV, PCI DSS, PA DSS, VISA, MasterCard, China UnionPay, JCB, AmEx, Discover, RuPay and etc.
Notes: FBI, STQC, EMV, PCIDSS, PADSS, Visa, MasterCard, China UnionPay, JCB, AmEx, Discover, RuPay is a registered trademark. All trademarks referenced here are the property of the respective owners.
